Hydraulic Portable Core Drilling Equipment For Geological Investigation / Exploration

besar.img.alt
kecil.img.alt kecil.img.alt kecil.img.alt kecil.img.alt

Gambar besar :  Hydraulic Portable Core Drilling Equipment For Geological Investigation / Exploration

Detail produk:
Place of Origin: China
Nama merek: Sinotechdrill
Sertifikasi: ISO
Model Number: TD-200YY
Syarat-syarat pembayaran & pengiriman:
Minimum Order Quantity: 1SET
Harga: negotiation
Packaging Details: Nude packing and wooden case available
Delivery Time: 5 days after payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20pcs per month
Detil Deskripsi produk
Nama Produk: 200 Meter Air Portabel & Rig Pengeboran Inti Aplikasi: Bor inti dan Sumur Air
Kedalaman bor: 200m diameter lubang: <300mm
Pengeboran sudut: 90-75 Berat bor (tidak termasuk daya): 975kg
Kekuasaan: Mesin diesel / motor listrik 22HP / 15KW Spindle stroke: 450mm
Cahaya Tinggi:

Underground peralatan pengeboran

,

underground drilling equipment

Rig pengeboran portabel hidraulik untuk investigasi & eksplorasi geologi

Spesifikasi

1. Sistem operasi hidrolik
2. Dilengkapi dengan roda
3. Mudah bergerak
4. Alat pengeboran pendukung yang sempurna

TD-200YY rig pengeboran dipasang trailer portabel hidrolik digunakan untuk penyelidikan umum Geologi dan eksplorasi, eksplorasi jalan dan bangunan tanah tinggi, jenis lubang dalam struktur beton, tanggul sungai, pengeboran lubang grouting tanah dasar dan grouting langsung, grouting sumur sumur, dan pendingin udara sentral bumi , dll.

TD-200YY

Parameter Mesin Unity
Kedalaman pengeboran 200 m
Maks. Diameter lubang 300mm
Diameter lubang ujung 75mm
Diameter pipa bor 60mm
Sudut pengeboran 90-75
Berat bor (tidak termasuk daya) 975kg
Belt Conveyer Segitiga B950x4 B1700x3
Mesin utama bergerak jaraknya 300mm
Kekuasaan Mesin diesel / motor listrik 22HP / 15KW
Poros
Kecepatan poros 64/128/287/557 r / mnt
Spindle stroke 450mm
Kerekan
Maks. Kapasitas angkat 2400kg
Kecepatan mengangkat satu baris 0,41 / 0,82 / 1,64 m / s
Kaliber Tightrope 13mm
Ukuran Tightrope 35mm
Peluk pintu air sekaliber 260mm
Peluk sabuk lebar pintu banjir 70mm
Pompa lumpur
Akting ganda horisontal guci tunggal
Maks. Pemindahan

Mesin diesel 170L / mnt

Motor listrik 150L / mnt

Maks. Tekanan 3Mpa
Tekanan pekerjaan 1.5Mpa
Diameter saluran masuk air 40mm
Diameter saluran air 30mm
Belt konveyor segitiga B1728
Pompa hidrolik
Mode CBT-F-314
Belt konveyor segitiga B1100-1
